COMPACT EXCAVATORS

The new Kubota K008-5 ultra-compact excavator lets you power through jobs with efficiency and versatility. You’ll enjoy a robust 10.3 horsepower rating, dominant hydraulic performance, two-speed travel and exceptional digging depth and height, as well as Kubota’s renowned durability. Let’s get to work.  Kubota is the world’s #1 selling compact excavator for 20 years.*

*According to 2023 data from Off-Highway Research including all Kubota Group brand sales.

Special Offers

  • Farmer Veteran Coalition Rebate

    Customer instant rebate for Farmer Veteran Coalition members.

    Farmer Veteran Coalition Rebate
  • Implement Stand Alone Financing

    Stand Alone Financing Installment Program

    Implement Stand Alone Financing
  • LOW-RATE RENTAL BUSINESSES*

    *Not Available for National Accounts or Government Customers

    LOW-RATE RENTAL BUSINESSES*
  • Construction

    $0 Down, 0% A.P.R. for up to 48 Months or Save up to $6,000 on Construction Equipment!

    Construction
Auxiliary

Auxiliary

  • Proportional flow control of auxiliary circuit (AUX1) and maximum oil flow setting – you can operate a larger variety of auxiliary attachments than ever before
  • Proportional AUX flow switch – a convenient bi-directional switch enables easy operation of hydraulic thumbs and other hydraulic attachments such as augers and breakers

K008-5

K008-5

HP

Specifications

Arm Breakout Force, Lbs (kgf)

1012 (458.9)

Auxiliary Hydraulics Flow Rate, G P M ( L P M)

5.5 (21.0)

Blade Height, In (mm)

7.9in (200)

Blade Width, Ft (mm)

2ft 4in / 2ft 10in (700 / 860)

Bucket Breakout Force, Lbs (kgf)

2205 (1000)

Crawler Length, Ft (mm)

4ft 0in (1230)

Displacement (cu. In.)

43.8

Engine Model

Kubota D722-E4

Fuel Reservoir, Gal (l)

3.2 (12.0)

Ground Contact Pressure Psi, Kgf (cm2)

4.1 (0.29)

Horsepower (gross)

10.3

Hydraulic Oil Reservoir / System, Gal (l)

3.60 / 4.8 (13.5 / 18.0)

Min. Ground Clearance, In (mm)

5.9in (150)

Operating Weight, Lbs (kg)

2315 (1050)

Overall Height, Ft (mm)

7ft 4in (2230)

Overall Length, Ft (mm)

9ft 0in (2750)

Overall Width, Ft (mm)

2ft 10in (860) / 2ft 7in (800)

Pump Capacity, G P M ( L P M)

2.8 (10.5) x 2

Traveling Speed: High, Mph (kph)

2.5 (4.0)

Traveling Speed: Low, Mph (kph)

1.2 (2.0)
